PVS0403U Function:

1. 10.1 inch FHD IPS LCD monitor

2. 2 x HDMI & 2 x 3G-SDI inputs, support auto-detected.

3. 2 x HDMI PGM output, 1 x HDMI multiview out, 1 x USB type-C output.

4. All outpus are configurable and assignable.

5. USB for capturing and streaming on PC.

6. Upstream key: Luma key, Chroma key, PIP x 2 / POP

7. Downstream key and LOGO overlay

8. T-bar/Auto/Cut transitions; various effects; WIPE(11 x 2 patterns) / MIX / DIP

9. Audio mixer: HDMI embedded audio and 2-CH Mic/Line in; audio delay available

10: Media library: 39 default patterns, 16 imported images, 16 captured imaged, 2 color generators

11. LAN port for PC software remote control.

12. FTB/ MUTE/ STILL/GPIO for tally.

HVS0403U FUNCTIONS:

1. 2 x HDMI & 2 x 3G-SDI inputs, support auto-detected.

2. 2 x HDMI PGM outputs, 1 x HDMI multiview output, 1 x USB type-C output.

3. All outputs are configurable and assignable.

4. USB for capturing and streaming on PC or Android phone.

5. Clearly visible multiview & status page.

6. Upstream key: Luma key, Chroma key, 2 x PIP/POP.

7. Downstream key and LOGO overlay.

8. T-bar / Auto/ Cut transitions; various effects: WIPE (11 x 2 patterns) / MIX/ DIP.

9. Audio mixer: HDMI embedded audio and 2-CH MIC/Line In; audio delay available.

10. Media library: 39 default patterns, 16 imported images, 16 captured images, 2 color generators.

11. LAN port for PC software remote control.

12. FTB/MUTE/STILL/GPIO for tally.

•

• HVS0402U is a 4-channel HDMI multi-format video Switcher with compact metal case design. It supports various functions including video switching, audio mixing, PGM/ multiview/ Aux out, different transition effects, Luma Key Chroma Key, DSK, LOGO, PIP/ POP, media library, pattern and color generator, etc.

•

• Inputs support multi-format, PGM output can be scaled, compatible with a variety of equipment. The unit supports stream performances and presentations on PC through the USB-C port. User can also customize different settings and import or export the configuration quickly for various scenarios. It’s a powerful and professional video switcher for your choices

•

• CHROMA KEY LUMA KEY CHROMA: Enable the Chroma Key LUMA: Enable the Chroma Key PIP1/PIP2: Enable two group of Picture in Picture. Size and position can be set via Menu. LOGO: Add logo bin from USB flash disk, enable the logo overlay ON AIR: make the corresponding Chroma/Luma/PIP/Logo on air

•

• T-Bar Switch the PVW and PGM through T-Bar

•

• . MULTIVIEW The switcher has two HDMI outputs (PGM/Multiview). The two HDMI ports are both the AUX out that user can define it as output of HDMI 1/ HDMI 2/ HDMI 3/ HDMI 4/ PGM/ Clean PGM/ PVW/ Color Bar/ Multiview (Refers to Part 6). Connecting the HDMI Multiview out to an additional monitor, user will get the multiview image. In the Multiview there are windows of PVW, PGM, HDMI 1, HDMI 2, HDMI 3, HDMI4 and Status/Menu page. See below image.

•
